SD-VUEExtend High-Resolution Video with USB up to 50m

  • High quality VGA video
  • Transparent USB 2.0 (low/full speed)
  • Integrated 4-port USB hub
  • Local video output
  • Compact footprint
  • Rack mountable

For businesses that require a cost-effective analogue KVM extender for a wide range of desktop applications, the SD-VUE ticks all the boxes. Proven technology, ergonomically-designed and with a small chassis footprint, it enables high-resolution video, USB, stereo audio and serial port signals to be communicated up to 50m over Category 5, 5e, 6 or higher (CATx) cable.

A 4-port USB hub is built into the USB remote unit which enables you to connect USB devices such as memory sticks, graphics tablets, custom controllers and other USB 1.1-compliant devices in addition to the keyboard and mouse.

Variants of the SD-VUE extend single or dual-head VGA signals but both models benefit from the local video outputs to allow for administrative monitoring.

The SD-VUE range is easy to install, easy to configure, and with such a small chassis footprint and highly attractive price point, it is perfect for those who require a robust, industry-proven analogue KVM extender that can be unobtrusively located.

At a glance features

  • Transparent USB 2.0 extension
  • Supports high VGA video resolutions
  • Emulated VESA Display Data Channel
  • Local video output on all video channels
  • Single and dual-head video support options
  • Transparent serial port option
  • Bi-directional stereo audio support option
  • Local Unit powered by USB
  • External PSU Overvoltage Protection
  • Status indicator LEDs and surge protection on each RJ45 port


SD-VUEUSB KVM Extender Manual
